BTL CardioPoint – Holter H300

BTL CardioPoint Holter H300 is a modern high-precision ECG Holter monitoring system designed for continuous long-term cardiac monitoring with advanced diagnostic and analytical capabilities.

• Number of channels: 3- or 7-channel
• Recording duration: 1–7 days
• Patient cable: 4 leads
• Data transmission: Wireless, USB
• LCD display resolution: 128 × 64 pixels
• Data storage: 2 GB SD card
• Dynamic range: ± 60 mV
• Digital resolution: 1.8 μV
• Sampling rate: 2000 Hz
• Frequency range: 0.05 Hz – 150 Hz
• Maximum electrode offset: ± 400 mV
• Common mode rejection (CMRR): > 100 dB
• Pacemaker detection: ≥ ± 2 mV / ± 0.1 ms
• Power supply: 2× AA Alkaline 1.5 V or 2× Ni-Cd / NiMH 1.2 V
• Dimensions: 102 × 62 × 24 mm (4” × 2.44” × 0.94”)
• Weight: 138 g
• Standards compliance: IEC 601-1, IEC 601-1-2, IEC 601-2-25, IEC 60601-2-47

• Continuous 1–7 day ECG Holter monitoring with 3 or 7 leads
• ST, PQ, QT, HRV, and rhythm analysis, including pacemaker detection and analysis
• Built-in display for ECG waveform visualization and recorded data review
• Patient activity monitoring
• High patient comfort ensured by compact dimensions and low weight
• Internal memory retains data even during power loss, allowing multiple data readings without any risk of data loss
• USB connection for fast data transfer to a computer
